FRAME
Hi Tensile Steel Cobra 20"
Top Tube Size: 20"
BB: AM Loose Ball
Headtube: Aheadset
Chainstay Length: 13.38"
Clamp: Integrated with Frame
BARS
Hi-Ten 8.5"
Upsweep/Backsweep 12ā°/1ā°
FORK
Cobra - Chromoly Steerer with Hi-tensile steel Tapered legs, 3/8" dropoutsĀ
Fork Rake: 28mm
HEADSETĀ Aheadset
STEMĀ Forged Alloy Top Load Stem
GRIPĀ Eastern Riblet Grips
CRANKĀ 3-Piece, Tubular Heat-Treated Chromoly, Bolt for Sprocket, Pinch Bolt with 8-Splined Spindle,Ā 170mm 28.6mm Round Arm
BOTTOM BRACKETĀ American Loose BallĀ
CHAINWHEELĀ Eastern Phorcys, Cold Hard Steel, 25T
CHAINĀ KMC Z510 1/2 x 1/8
PEDALĀ Eastern Atom Plastic Pedal with 9/16" Axle
FRONT BRAKEĀ N/A
FRONT LEVERĀ N/A
|
REAR BRAKEĀ U-Brake, Forged Alloy, Wide Body, Grey Brake Pads
REAR LEVERĀ Forged Alloy Lever
BRAKE CABLEĀ [S] LINEAR
SADDLEĀ Padded Seat with Railed Supports
POSTĀ Steel 200mm
FRONT HUBĀ Sealed Bearings, Forged Alloy Shell, Drilled for 36 Spokes, 3/8" Chromoly Axle
REAR HUBĀ Sealed Bearings, Forged Alloy Shell Drilled for 36 Spokes, 14mm Chromoly Axle
FREEWHEELĀ 9 Tooth Sealed Driver with Hub
FRONT RIMĀ Alloy, Single Wall, Drilled for 36 Spokes. For 20" Tires
REAR RIMĀ Alloy, Single Wall, Drilled for 36 Spokes. For 20" Tires
SPOKESĀ 14 Gauge with Brass Nipples
FRONT TIREĀ 20 x 2.3 *Specs subject to change
REAR TIREĀ 20 x 2.3 *Specs subject to change
PEGĀ none
|
